1440-TB-C | Allen-Bradley | Screw Clamp C Terminal Base

Description

The 1440-TB-C is an Allen-Bradley Screw Clamp C Terminal Base, part of the XM series (per reference to the similar 1440-TB-B model). Key features include a compact, rugged design, universal compatibility, and easy installation, making it suitable for harsh industrial environments. It uses a screw clamp termination method to provide secure, reliable electrical connections, and is engineered to work with all 1440-xx-01RB series measurement modules. Technical specifications (based on the comparable 1440-TB-B model) include a 24V DC supply voltage, 6A maximum and rated fixed operating current, and an IP20 protection rating. Physical dimensions are 12.5mm width, 98.5mm height, 80mm depth, with a module weight of approximately 0.13 lb. It supports two push-in terminal wire gauge options: PT10 for AWG20 to AWG8 (0.5 to 10 square meters) and PT2.5 for AWG24 to AWG14 (0.14 to 2.5 square meters). This terminal base facilitates signal collection and transmission for vibration, pressure, and temperature monitoring, and is ideal for industrial automation applications including condition monitoring, fault diagnosis, process control, and predictive equipment maintenance.
