1MRK000008-LBR02 ABB Front Display Panel for Protection Relays
Description
1MRK000008-LBR02 ABB Front Display Panel for Protection Relays is a dedicated human-machine interface (HMI) component designed to pair with ABB protection relays, enabling intuitive monitoring and control of relay functions in industrial power systems.
| Specification | Value |
|---|---|
| Mounting Torque | 0.7 Nm ± 0.2 Nm for fixing screws |
| Communication Cable Requirements | Shielded twisted pair, minimum 0.25 mm2 (AWG 24), max 52.5 pF/m capacitance |
| Power Supply Isolation | Requires insulated 24V feed to prevent communication interference |
Key Features:
- High reliability and strong anti-interference performance for stable operation in industrial environments
- Supports secure communication with protection relays via properly shielded cabling
- Compact, space-saving design suitable for integration into control cabinets and relay cubicles
- Tool-assisted installation with included hardware for secure mounting
Applications:
- Monitoring and control of generator protection relays in power generation facilities
- Interface for protection relay systems in industrial power distribution networks
- Integration into pre-wired, factory-tested protection relay cubicles
Related Models:
- PP874K (Panel 800 standard keypad panel)
- PP871 (Panel 800 standard touch panel)
- PP882 (Panel 800 advanced performance panel)
