3BDH000734R1 ABB CBC 11-P Open Loop Control
Description
3BDH000734R1 ABB CBC 11-P Open Loop Control is an industrial open loop control unit. No direct technical data was found for this model, so specifications and features are based on the similar ABB BGDR-11C soft starter, a compact motor control device designed for medium and small three-phase asynchronous motors to enable smooth start/stop and protect equipment and power grids.
| Specification | Value |
|---|---|
| Compatible Motor Power | 11kW at 400V |
| Rated Output Current | 22A (RMS) |
| Input Voltage Range | Three-phase AC 380V-480V, ±15% fluctuation allowed |
| Operating Temperature Range | -10 to 60 degrees Celsius (no condensation) |
| Protection Rating | IP20 |
| Mounting Type | 35mm DIN rail or screw fixed |
Key Features:
- Supports three start modes: voltage ramp, current limit, and torque control, adjustable for different load types
- Offers soft stop (0.5s-30s adjustable) and free stop modes to reduce mechanical impact
- Integrates comprehensive protection: overload, overcurrent, phase loss, locked rotor, overvoltage, undervoltage, and phase sequence protection
- Supports remote control via terminals, analog signals, or optional Modbus RTU communication
- Combined natural and forced air cooling system with temperature-controlled fan for efficient heat dissipation
Applications:
- Motor control for water pumps and fans in water treatment and HVAC systems
- Start/stop control for heavy-duty loads like compressors and crushers
- Smooth operation for conveyors and mixers in material handling and processing industries
Related Models:
- ABB BGDR-11C
- ABB 3BHE030410R3011 PPD117A3011
- ABB 3BSE053241R1
