5SHX1060H0003 3BHB020538R0001 ABB Industrial IGCT Module
Description
5SHX1060H0003 3BHB020538R0001 ABB Industrial IGCT Module is a high-power semiconductor device that combines the functions of a thyristor and rectifier, designed for medium-voltage drive and power conversion applications.
| Specification | Value |
|---|---|
| Rated Voltage | 180V DC |
| Maximum Transient Peak Output Current | 3000A |
| Maximum Switching Frequency | 350kHz |
| Maximum Power Loss | 50W |
| Dimensions | 220mm × 160mm × 50mm |
| Weight | 1.2kg |
| Protection Grade | IP20 |
| Operating Temperature Range | -10 to 50 degrees Celsius (full load) |
Key Features:
- High blocking voltage, large current capacity, and low on-state power loss
- Supports vector control and direct torque control (DTC) methods
- Built-in hardware-level protection for overcurrent, overvoltage, undervoltage, overheating, and short circuits
- Optional PROFIBUS-DP and DeviceNet communication interfaces
- Supports incremental encoder and SSI absolute encoder feedback interfaces
- Standard DIN rail mounting for easy installation
Applications:
- Industrial drive systems such as rolling mill main drives, hoists, fans, and water pumps
- Rail transit systems including subway traction systems and high-speed rail power supply equipment
- Medium-voltage frequency converters and renewable energy grid-connected equipment
Related Models:
- 5SHX10H6004
- 5SHX10H6010
- 3BHL001863P0001
- 3BHB023302R0001
- 5SHY4045L0006
