5SHX10H6004 ABB Power Module
Description
5SHX10H6004 ABB Power Module is a dual-category product available as either a soft starter for AC induction motors or a high-performance Integrated Gate Commutated Thyristor (IGCT) module, designed for industrial and power electronic applications.
| Specification | Value |
|---|---|
| Product Type (Soft Starter Variant) | AC Induction Motor Soft Starter |
| Product Type (IGCT Variant) | Integrated Gate Commutated Thyristor Module |
| Rated Power (Soft Starter) | 10 horsepower (7.5 kilowatts) |
| Rated Voltage (Soft Starter) | 230 – 460V AC |
| Rated Current (Soft Starter) | 25A |
| Start Current (Soft Starter) | 150% of full load current |
| Maximum Start Torque (Soft Starter) | 150% of full load torque |
| Dimensions (Soft Starter) | 220mm x 160mm x 100mm |
| Weight (Soft Starter) | 5 kilograms |
| Protection Class (Soft Starter) | IP20 |
| Current Handling Capacity (IGCT) | Approximately 1900A |
| Operating Temperature Range (IGCT) | -40 to 85 degrees Celsius |
Key Features:
- Soft Starter Variant: Gradual motor speed increase to reduce startup torque, current, and mechanical/electrical stress; multiple protection functions including overcurrent, undervoltage, overvoltage, phase loss, and ground fault; compact space-saving design; easy configuration via DIP switches or communication interfaces
- IGCT Variant: Combines fast transistor turn-off with high voltage/current tolerance of thyristors; high efficiency and fast switching performance; stable operation in harsh power environments; optimized for low conduction losses
Applications:
- Soft Starter Variant: Pumps, fans, conveyors, machine tools, HVAC systems, compressors, and material handling equipment
- IGCT Variant: Medium-high voltage frequency converters, static var compensators, high-voltage DC transmission systems, and large power electronic control systems
Related Models:
- 5SGX10H6004
- 5SXE05-0152
- 3BHB003230R0101
