5SHX19L6010 ABB Flat Panel SCR IGCT Module
Description
5SHX19L6010 ABB Flat Panel SCR IGCT Module is a high-performance Integrated Gate-Commutated Thyristor module manufactured by ABB in Switzerland, designed for medium and high voltage power control applications.
| Specification | Value |
|---|---|
| Control Power Consumption | 10-100W |
| Typical Switching Frequency | 500 Hz |
| Maximum Short Switch Pulse Train Frequency | 40 kHz |
| Product Type | IGCT (Integrated Gate-Commutated Thyristor) Module |
Key Features:
- Press-fit device mounted to heat sink with high force, using heat sink as power terminal electrical contact
- Integrated on/off control unit accessible via fiber optic connection, requiring only external power supply
- Optimized for low conduction losses, with fast transition enabling short switch pulse trains up to 40 kHz
- Improved turn-off performance with expanded safe operating area, eliminating need for snubber circuits
Applications:
- Medium and high voltage variable frequency drives
- Distributed control systems, programmable logic controllers, panel controllers, and drive systems
- High power applications ranging from 0.5 to 6 MVA, scalable to hundreds of MVA via series/parallel connections
