8C-PDILAI Honeywell Analog Input Module Quick Response

Description

The 8C-PDILAI Honeywell Analog Input Module is a high-performance industrial input module designed for reliable, quick-response analog signal acquisition. Equipped with a dual redundant backplane bus for enhanced operational continuity and pluggable terminal blocks for easy wiring and maintenance, it supports 8 current input channels with a signal range of 0~20mA or 4~20mA. Key technical specifications include a 16-bit resolution (including sign bit), a fast transition time of 8ms for all 8 channels at filter level 0, and low measurement error: ≤±0.2% at 25 degrees Celsius, and ≤±0.4% across the full operating temperature range of -35 degrees Celsius to 60 degrees Celsius (horizontal installation) or -35 degrees Celsius to 50 degrees Celsius (vertical installation). It draws 52mA at 5VDC, accepts wiring diameters from 0.2 square mm (AWG24) to 1.5 square mm (AWG16), and mounts on a 35mm DIN rail with dimensions of 119*14*80mm. Built-in diagnostic functions cover ADC fault detection, open circuit detection, and overflow/underflow monitoring. The module meets CE certification, has an IP20 protection rating, complies with IEC61131-2 and IEC61000-4 EMC standards, and operates in environments with 5% to 95% RH (no condensation) at altitudes below 2000m.
