ABB 5SHX1060H0002 3BHL000388P0101 High-Quality IGCT Module
Description
ABB REF615 is an advanced intelligent power protection and control device from the ABB Relion® series, designed for medium and high voltage distribution systems. It provides comprehensive protection, control, measurement, and monitoring capabilities for power system components, with fast response and reliable performance.
| Specification | Value |
|---|---|
| Input Voltage | 100-240VAC, 48-250VDC |
| Operating Temperature | -40 to 70 degrees Celsius |
| Storage Temperature | -40 to 85 degrees Celsius |
| Protection Rating | IP54 (front), IP20 (rear) |
| Supported Protocols | IEC 61850, PRP, HSR, Modbus RTU/TCP, DNP3 |
Key Features:
- Drawer-type design for easy installation and maintenance
- Supports underground and overhead cable fault detection (CFD) and high impedance (HIZ) fault detection
- Equipped with 32-bit high-performance processor for millisecond-level signal acquisition and judgment
- Integrated self-monitoring and event sequence recording (SOE) functions
- Modular structure allows targeted component replacement for reduced maintenance costs
Applications:
- Feeder, transformer, and motor protection in utility and industrial substations
- Medium and high voltage distribution networks, including radial, ring, and network configurations
- Renewable energy systems such as wind and solar power facilities
- Industrial facilities including cement, metallurgy, petrochemical, and semiconductor plants
Related Models:
- REF615A_1G
- REF615C-E
- REF615E_E
- REF615K
- REF615D
