ABB 5SHX2645L0002 IGBT/IGCT Module
Description
ABB 5SHX2645L0002 IGCT/IGBT Module is a high-performance power electronic module from ABB’s 5SHX series, available in both IGCT (Integrated Gate-Commutated Thyristor) and IGBT (Insulated Gate Bipolar Transistor) configurations, designed for high-voltage, high-current power control and conversion applications.
| Specification | Value |
|---|---|
| Rated Current | 2645 A, up to 4000 A |
| Rated Voltage | 1000 V, up to 4500 V |
| Frequency | 50/60 Hz |
| Cooling Method | Natural cooling, optional forced air cooling |
| Protection Class | IP20 |
| Operating Temperature Range | -40 to 85 degrees Celsius |
| Conduction Voltage Drop | Approximately 2.5 V |
Key Features:
- High performance with strong high-voltage and large-current handling capability
- High reliability with premium materials, integrated protection, and fault diagnosis functions
- Low power loss due to low conduction voltage drop and efficient switching design
- Fast switching speed, suitable for high-frequency applications
- Easy to use with simple control interface and status feedback for monitoring
Applications:
- Renewable energy systems including wind power and photovoltaic inverters
- Industrial automation such as servo motor drives and PLC control systems
- Power conversion equipment including UPS and power converters
- Transportation applications like electric vehicles and electrified railways
- Power system reactive power compensation for industrial grids and data centers
Related Models:
- ABB 5SHX2645L0001
- ABB 5SHX2645L0004
- ABB 5SHX1960L0006
- ABB 5SHX1445H0002
