ABB AO845A Analog Output Module

Description

The ABB AO845A Analog Output Module is a component of the ABB S800 I/O system, designed for industrial automation and process control applications. It features 8 independent analog output channels, each supporting selectable 4-20mA or 0-10V analog signal outputs, with a maximum output current of 1A per channel. The module supports multiple communication protocols including PROFIBUS-DP, Modbus, and HART, enabling seamless integration with diverse industrial control systems, and it also supports HART pass-through communication for enhanced device configuration and monitoring.

Equipped with robust self-diagnostic capabilities, the module performs continuous cyclic self-checks to monitor its operational status, reporting faults such as external channel issues (low process power, open circuits with setpoint >1mA), internal channel errors (incorrect current output), and module-level faults (output transistor failures, short circuits, checksum errors, internal power issues, status link errors, watchdog triggers, or abnormal OSP behavior). It supports redundant configuration for single or redundant applications, significantly improving system reliability.

Key technical specifications include 12-bit resolution with ±0.1% accuracy, 24V DC input voltage, IP20 protection rating, operating temperature range of -20 degrees Celsius to 70 degrees Celsius, and dimensions of 71 x 106 x 22 mm with a weight of approximately 0.1 kg. The module also provides short-circuit protection for analog outputs and is suitable for use in process control, mechanical automation, and building automation scenarios.
