ABB AR C093 AE01 HIEE300690R0001 Relay Output Card
Description
ABB AR C093 AE01 HIEE300690R0001 Relay Output Card is a dedicated relay output board for the ABB UNITROL 6000 excitation system, providing 16 channels of relay output for high-power control tasks such as tripping, alarming, and signal switching.
| Specification | Value |
|---|---|
| Output Type | 16 channels SPDT (Single Pole Double Throw) relays |
| Contact Capacity | 250V AC/5A, 30V DC/5A (resistive load) |
| Power Supply | 24V DC |
| Isolation | Electrical isolation between output channels, and between channels and system |
| Diagnostic Functions | Contact adhesion detection, overcurrent protection, communication anomaly alarm |
| Operating Temperature | -20 to 60 degrees Celsius |
| Storage Temperature | -40 to 85 degrees Celsius |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | Approximately 0.76kg |
Key Features:
- 16 independent relay output channels for flexible high-power control
- Contact capacity optimized for strong electrical control applications
- Seamless communication compatibility with ABB UNITROL 6000 controllers
Applications:
- Generator excitation systems in thermal, hydro, and nuclear power plants
- Industrial high-power control scenarios such as large rectifier/inverter equipment start-stop control
- Reactive power compensation system capacitor/inductor switching
- Safety interlock control for rolling mills and mine hoists
- Grid fault isolation and protection, energy storage converter grid/off-grid switching
Related Models:
- ABB ARC093A V1 HIEE300690R1
- ABB 1SVR730824R9300 CM-PFS.S
- ABB 3BHE009319R0001
