ABB AX521 C1 S500 Analog I/O Module
Description
ABB AX521 C1 S500 Analog I/O Module is a configurable analog input/output module designed for industrial automation systems, part of the ABB S500 I/O module series. It handles multiple analog signal types to support diverse control and monitoring tasks.
| Specification | Value |
|---|---|
| Number of Input Channels | 4 configurable analog inputs |
| Number of Output Channels | 4 configurable analog outputs |
| Supported Input Signal Types | 0-10V, ±10V, 0/4-20mA, PT100, PT1000, NI1000 |
| Supported Output Signal Types | ±10V, 0/4-20mA |
| Resolution | 12 bits |
| Power Supply | 24VDC |
Key Features:
- High flexibility via fieldbus plug-in technology for connection to nearly any fieldbus
- High compatibility with ABB Microflex E190 and Motiflex E180 servo drives; supports Modbus TCP client function via firmware upgrade
- Optimized processing for efficient performance, and can be combined with other ABB I/O modules for expanded functionality
Applications:
- General industrial automation control systems requiring analog signal input and output
- Temperature, pressure, and flow monitoring and control applications
- Centralized or distributed automation setups with complex signal handling needs
