ABB CC-U/STDR Universal Signal Converter
Description
ABB CC-U/STDR Universal Signal Converter is a universal analog signal converter designed to amplify, convert, isolate, and measure various analog signals, ensuring safe and reliable operation of industrial plant processes.
| Specification | Value |
|---|---|
| Rated Supply Voltage | 24 – 48 V DC |
| Accuracy | 0.1% of full scale |
| Response Time | 200 seconds |
| Input Signal Range | 0.9 mA – 55 mA / 45 mV – 11 V / 470 ohms – 1 ohm |
| Output Signal Range | 0 – 55 mA / 0 – 11 V |
| Environmental Temperature Range | -20 to 60 degrees Celsius / -40 to 80 degrees Celsius |
| Dimensions (L x W x H) | 12.0 x 2.25 x 10.5 cm |
| Weight | 0.125 kg |
Key Features:
- Over 120 configurable settings via DIP switches
- 3-way electrical isolation for signal integrity
- Configurable output response (low fail-safe / high fail-safe) for input signal interrupts
- Front-panel potentiometers for precise adjustment
- Short-circuit protected output signals and pluggable terminals for input, output, and power
Applications:
- Industrial automation systems for signal matching and data transmission
- Process control plants to maintain stable operation of connected equipment
- Manufacturing facilities requiring reliable signal conversion between diverse devices
