ABB DSQC609 3HAC14178-1 Power Module is a dedicated 24V DC power module for ABB IRC5 series robot controllers, serving as the core power supply unit for internal critical components.
| Specification | Value |
|---|---|
| Input Voltage | 100-240V AC, 50/60Hz |
| Output Voltage | 24V DC, 2A rated current, 48W maximum power |
| Efficiency | ≥90% |
| Dimensions | 84.6×48×17.5mm |
| Net Weight | 0.3kg |
| Operating Temperature | -20 to 55 degrees Celsius |
| Protection Rating | IP20 |
Key Features:
- Converts external AC input to stable 24V DC for controller internal core circuits
- Built-in overvoltage, undervoltage, overload, short circuit, and overheat protection
- On-board LED indicators for power status, fault, and output diagnostics
- Modular design for direct backplane slot installation and quick replacement
- Passes CE, UL, CSA safety certifications
Applications:
- Power supply for IRC5 controller internal core components including CPU, axis computer, communication boards, and I/O modules
- Base power support for ABB IRC5 series robot control systems
Related Models:
- ABB PSM0004 2RCA025059A0001R
- ABB 3HAC020578-001
- ABB 3HAC17281-1
