ABB CI810B AF100 Field Communication Interface
Description
ABB CI810B AF100 Field Communication Interface is a modular fieldbus communication interface designed to connect controllers and field devices in industrial automation systems, enabling reliable data collection, control, and monitoring.
| Specification | Value |
|---|---|
| Product Number | 3BSE020520R1 |
| Weight | 0.5 kilograms |
| Overall Dimensions | 273 mm height, 40 mm width |
| Net Dimensions | 250 mm height, 158 mm width, 87 mm depth |
| Operating Voltage | 24 VDC power supply |
| Operating Temperature | 0 to 60 degrees Celsius |
| Operating Humidity | 5 to 95 percent, non-condensing |
| Software Version | Basic system software 1.5 |
Key Features:
- Integrated 2*AF100 twisted pair modem
- Supports multiple fieldbus protocols including Profibus DP, Modbus RTU, Foundation Fieldbus, and EtherNet/IP
- Stable and reliable communication performance
- Compact, space-saving modular design for easy installation and maintenance
- Includes accessories: power connector 3BSC840098R1, TB807 Modulebus terminator 3BSE008538R1, AF100 connector 3BSC840105R1, and 2 terminal blocks
Applications:
- Chemical, power, petroleum, pharmaceutical, and food processing industries
- Industrial automation systems for connecting PLCs and field instruments
- Data transmission and process monitoring in manufacturing and water treatment facilities
