ABB CI860K01 Power Module Rack Power Supply Unit
Description
ABB CI860K01 (3BSE032444R1) is a communication interface module for the AC 800M control system, designed to connect FOUNDATION Fieldbus HSE (High Speed Ethernet) networks for efficient data communication with field devices. It is powered via the CEX bus by the processor unit, eliminating the need for an external power supply.
| Specification | Value |
|---|---|
| Power Supply Voltage | 24 VDC |
| Power Consumption | 2 W |
| Communication Rate | 31.25 kbps to 2 Mbps |
| Operating Temperature | -25 to 70 degrees Celsius |
| Dimensions | 125 x 75 x 30 mm |
| Weight | 0.5 kg |
Key Features:
- Supports FOUNDATION Fieldbus HSE networks to connect AC 800M controllers to HSE subnets for reliable communication
- Redundant configuration support to enhance system reliability; up to 12 CI860 modules can be used per AC 800M controller
- Modular structure for easy installation, maintenance, and system expansion across different automation scales
- Industrial-grade design with strong anti-interference capability for stable operation in harsh industrial environments
Applications:
- Oil and gas industry for pipeline monitoring and wellhead control
- Chemical industry for automation control and data collection in hazardous areas
- Power systems for process control in power plants and substations
- Water treatment for remote monitoring of wastewater treatment plants and water supply facilities
Related Models:
- CI820V1
- FI840F
- PM803F
- CI801
