ABB Commander 1900 general-purpose circular chart recorder
Description
ABB Commander 1900 General-Purpose Circular Chart Recorder is a fully programmable paper-based circular chart recorder designed to monitor up to four process signals, offering high flexibility for industrial monitoring needs.
| Specification | Value |
|---|---|
| Recording Pens | 1 to 2 pens |
| Measurement Accuracy | 0.1% |
| Chart Speed | 1 to 167 hours per rotation, or 7 to 32 days per rotation |
| Chart Size | 10 inches or 105 millimeters |
| Input Types | Isolated universal inputs with transmitter power; analog inputs include MV, V, mA, Ohm, Pt100; thermocouple inputs include B, E, J, K, L, N, R, S, T |
| Operating Voltage | 115/230V AC |
| Dimensions | 382 x 386 x 134 millimeters |
| Protection Rating | NEMA4X/IP66 |
Key Features:
- Up to 4 trace recording with independently settable pen ranges for high signal resolution
- Advanced built-in EMC shielding ensures accurate recording in noisy industrial environments
- Flexible installation options: wall, pipe, or panel mounting
- 6-digit process status display shows up to four process values simultaneously with activated alarms
- Password-protected menu system prevents unauthorized configuration changes
- Built-in accumulators, configurable mathematical functions, and mass flow calculation support
Applications:
- Industrial process monitoring and data logging
- Pharmaceutical manufacturing and laboratory testing
- Power plant operation and transportation system monitoring
Related Models:
- C1900-R
- C1900/0121 (replacement red pen accessory)
- 500P1225-1 (replacement chart paper)
