ABB CS513 IEEE 802.3 LAN-Module
Description
ABB CS513 3BSE000435R1 IEEE 802.3 LAN-Module is a communication module designed to connect ABB AC800M controllers to Ethernet networks, enabling data communication between the controller and other devices while expanding the controller’s functionality for additional applications.
| Specification | Value |
|---|---|
| Model Number | CS513 3BSE000435R1 |
| Interface Type | RJ45 |
| Communication Protocol | IEEE 802.3 |
| Transmission Rate | 10/100 Mbps adaptive |
| Operating Mode | Half-duplex/full-duplex adaptive |
| Power Supply | 24 VDC |
| Operating Temperature | -25 to 55 degrees Celsius |
| Protection Rating | IP20 |
| Dimensions (LxWxH) | 234 mm x 108 mm x 18 mm |
| Net Weight | 0.2 kg |
Key Features:
- Supports IEEE 802.3x flow control and 802.1Q VLAN for optimized network performance and segmentation
- Built-in switch enables connection of multiple terminal devices to form local area networks
- Complies with IEC and NEMA standards, with rigorous testing for reliable long-term operation
- Standard RJ45 interface allows for quick, tool-free installation and integration
- Compatible with existing ABB AC800M controllers for seamless system expansion
Applications:
- Industrial automation control systems
- Power generation and distribution systems
- Transportation infrastructure monitoring and control
- Building automation and facility management systems
- Distributed control systems (DCS) for process industries
Related Models:
- ABB 3BSE000434R1 LAN Module
- ABB 3BSE019943R1 Controller Module
- ABB CI547 3BNP004429R1 Digital Module
