ABB DLM 01 Link Module DLM01
Description
ABB NETA-01 Ethernet Adapter Module is an industrial network interconnection component designed to enable seamless device connectivity and data exchange, bridging traditional industrial equipment with modern Ethernet systems to support digital transformation.
| Specification | Value |
|---|---|
| Interface Type | 2×RJ45 Ethernet ports (10/100Mbps auto-negotiation), 1×RS-485 serial port, 1×USB 2.0 (for debugging) |
| Protection Rating | IP30 |
| Operating Temperature | -25 to 70 degrees Celsius (storage: -40 to 85 degrees Celsius) |
| Power Supply | 24VDC (±15%), supports dual redundant power input |
| Mounting | DIN rail mounting, compatible with ABB AC500/AC500-eCo PLCs and third-party standard racks |
| Dimensions & Weight | 110mm×80mm×45mm, approximately 0.3kg |
| Connection Capacity | Up to 32 devices (RS-485 side), 128 devices (Ethernet side) |
| Certifications | CE, UL, cUL, Class I Div 2, IEC 62443 |
Key Features:
- Multi-protocol compatibility, supporting Modbus TCP/RTU, Profinet, EtherNet/IP, and OPC UA (with configuration) for cross-brand device integration
- High-speed data transmission via dual RJ45 ports, meeting real-time monitoring and large data transfer requirements
- Redundant power design with automatic switchover to backup power during main supply failure for uninterrupted operation
- Industrial-grade durability with wide temperature range and IP30 rating, suitable for harsh environments with dust, vibration, and electromagnetic interference
- IEC 62443 certified network security with VLAN division, user access control, and data encryption to prevent cyber attacks
Applications:
- Automated production lines for real-time data upload to MES systems, supporting process optimization and quality tracking
- Renewable energy facilities, converting RS-485 signals from inverters and meters to Modbus TCP for SCADA-based remote monitoring
- Smart buildings, connecting HVAC, lighting, and security systems to BMS via OPC UA for energy efficiency management
- Water treatment plants, converting device signals to Profinet for central control room process parameter regulation
