ABB DO880 High-Speed Digital Output Module for Automation Networks
Description
ABB DO880 High-Speed Digital Output Module for Automation Networks is a high-performance digital output module designed for industrial automation and control systems, supporting both single and redundant configurations.
| Specification | Value |
|---|---|
| Product Model | DO880 |
| Product Code | 3BSE028602R1 (may vary by production batch) |
| Number of Channels | 16 channels |
| Output Type | 24V DC current source |
| Maximum Continuous Output Current per Channel | 0.5A |
| Safety Certifications | IEC 61508 SIL3, EN 954-1 Category 4 |
| Net Weight | 0.32 kilograms |
Key Features:
- Each output channel includes high-side driver with current limiting and over-temperature protection, EMC protection components, and inductive load suppression
- Supports loop monitoring for short-circuit and open-circuit loads with configurable limits, plus advanced on-board diagnostics and pulse-free output switch diagnostics
- Equipped with LED status indicators to show active or error states
- Supports both redundant and single configuration for flexible system design
- Offers fault tolerance level 1 for output drivers as defined in IEC 61508, with maintainable output control during driver errors for normal de-energization systems
- Supports degraded mode for normally energized channels (supported by DO880 PR:G)
Applications:
- Manufacturing, chemical, petroleum, and natural gas industries
- Power generation facilities including thermal, nuclear, wind, and new energy plants
- Shipbuilding, transportation, steel production, and water treatment systems
- Integrated automation systems such as ABB Ability System 800xA
Related Models:
- DO880-1
