ABB DX571 input/output (I/O) module
Description
ABB DX571 Input/Output (I/O) Module is a modular analog input/output module designed for industrial automation systems, compatible with PLC/DCS platforms as part of the ABB AC500 S500 I/O series.
| Specification | Value |
|---|---|
| Origin | Germany, United States, or Japan |
| Structure Type | Modular, vertical layout |
| Housing Material | Plastic |
| Dimensions | 12.80 x 15.30 x 5.20 cm |
| Rated Supply Voltage | 24V DC |
| Operating Temperature Range | -20 to 60 degrees Celsius |
| Power Supply | 15V |
| I/O Points | 8 |
| Output Frequency | 8 |
| Interface Type | PROFINET |
| Isolation | Potential isolation |
| Program Capacity | 268 |
| Certifications | CE, ST72-CN |
| Process Side Connection | Jack panel |
Key Features:
- Good operability and stable performance
- Updatable firmware version
- Supports multiple transmission media, including shielded twisted pair with terminal resistor complying with RS485 bus specification
- Allows PLC program division into structural blocks via flowcharts, with logic relationships defined using ladder diagrams
- Enables efficient use of internal PLC soft components to reduce hardware investment
- Integrates diagnostic functions with detailed information displayed for quick troubleshooting
Applications:
- Industrial automation control systems
- PLC/DCS system expansion and signal processing
- Switching logic control applications
Related Models:
- DX561
- DC561
- MC-TDOY23
- MU-TDID12
- MC-TSIM12
