ABB FI 830F PROFIBUS-DP Fieldbus Module
Description
ABB FI 830F PROFIBUS-DP Fieldbus Module is a high-performance fieldbus interface module part of the ABB AC800F series controllers, designed to connect PLCs with field devices for data collection, transmission, and control output. It supports multiple communication protocols for flexible integration into various industrial systems.
| Specification | Value |
|---|---|
| Module Type | PROFIBUS-DP Fieldbus Module |
| Working Voltage | 24V DC |
| Maximum Communication Rate | 12 Mbps |
| Communication Interfaces | RS485, Ethernet, PROFIBUS-DP |
| Maximum Connected Slaves | 126 |
| Maximum Communication Distance | 1000 meters |
| Protection Class | IP20 |
| Dimensions | 71mm x 137mm x 71mm |
| Weight | Approximately 500 grams |
| Operating Temperature Range | -20 to 60 degrees Celsius |
| Storage Temperature Range | -40 to 85 degrees Celsius |
| Mounting Method | DIN Rail Mount |
Key Features:
- Modular design for easy installation, maintenance, and upgrade
- Industrial-grade components for high reliability and stable operation in harsh industrial environments
- Supports multiple protocols including PROFIBUS-DP, Modbus RTU, and Modbus TCP for flexible configuration
- High-speed data transmission to improve control system response time
- Supports hot-swapping and redundant master operation for enhanced system availability
Applications:
- Process control in chemical, petroleum, power, and metallurgy industries
- Machine and production line automation in manufacturing and automotive sectors
- Building automation for HVAC system control
- Energy management and robot control systems
