ABB FSM4000 Electromagnetic Flowmeter
Description
ABB FSM4000 Electromagnetic Flowmeter is a robust, heavy-duty volumetric flowmeter based on Faraday’s induction principle, designed to accurately measure conductive liquids, slurries, and pulps while saving resources through precise process parameter monitoring.
| Specification | Value |
|---|---|
| Nominal Diameter | DN 3 to 1000 (1/10 to 40 inches) |
| Nominal Pressure | PN 10 to 40, ASME CL150, CL300 |
| Process Connection | Flanges compliant with DIN/EN, ASME standards |
| Lining Materials | PFA, PTFE, hard rubber, soft rubber, ceramic carbide |
| Accuracy | <±0.5% of rate (for DN > 2) |
| Fluid Temperature | -40 to 130 degrees Celsius (-40 to 266 degrees Fahrenheit), optional up to 180 degrees Celsius (356 degrees Fahrenheit) |
| Power Supply | AC/DC |
| Communication Protocols | HART standard; optional PROFIBUS PA, Foundation Fieldbus |
| Hygiene Certifications | 3A, EHEDG |
Key Features:
- No moving or protruding parts, no additional pressure drop, wear-resistant and corrosion-resistant
- Digital signal processing and zero stability ensure long-term accuracy and bidirectional measurement stability
- Enhanced diagnostic functions monitor coil, electrode circuits, and magnetic field for operational reliability
- Wide range of industry-specific linings and electrodes to meet harsh application demands
- Compatible with standard installation lengths for DIN, ASME B16.5, or JIS B2210-10K flanges
Applications:
- Pulp and paper industry for high-solid-content and abrasive fluid measurement
- Food and beverage industry for hygienic, pulsating, or unevenly conductive fluid measurement
- Mining industry for corrosive and abrasive slurry measurement
Related Models:
- FSM4000-SE21F: Flange-type sensor for food and beverage industry
- FSM4000-SE21: Flexible process connection sensor for food and beverage industry
- FSM4000-SE41F: Flange-type sensor with PTFE or rubber lining for pulp, paper, and mining industries
