ABB NINT-68C Inverter Control Board
Description
ABB NINT-68C Inverter Control Board is a 16-channel isolated digital input/output module designed for use with Modicon Quantum series controllers, featuring an additional analog input for monitoring I/O status.
| Specification | Value |
|---|---|
| Digital Inputs | 16 channels, 24 VDC, 250 mA |
| Digital Outputs | 16 channels, 24 VDC, 500 mA |
| Analog Input | 1 channel, 24 VDC, 20 mA |
| Dimensions | 100 x 76 x 26 millimeters |
| Weight | 0.2 kilograms |
| Brand | ABB |
| Series | DI814 |
| Origin | Switzerland |
| Operating Voltage | 220 V |
| Output Frequency | 50 Hz |
Key Features:
- Each digital input and output can be programmed individually for flexible configuration
- Integrated isolation to prevent electrical interference between signals
- Constructed with high-quality components for reliable long-term performance
- Easy to install and operate for quick integration into control systems
- Analog input enables real-time monitoring of digital I/O status
Applications:
- Industrial automation systems
- Building automation and control
- Mechanical equipment control
- Power system monitoring and management
