ABB XVC722AE02 Circuit Interface Module
Description
ABB XVC722AE02 Circuit Interface Module is an industrial automation controller module that serves as the control core for drives, integrating control power, modulation pulse generation, control mode, and protection logic circuits. It accepts signals from panels and external control interfaces to control and protect radio frequency unit operation, while transmitting drive status signals back to panels and external control interfaces.
| Specification | Value |
|---|---|
| PWM Pulse Generator | SG352 series chip |
| Output Pulse Frequency Range | 20KHz – 60KHz |
| Pulse Interval | 180 degrees |
| Applicable Power Range | 10KW – 120KW |
| Operating Power Supply | Three AC dual 18V/1A and four 22V/0.xxA sources |
Key Features:
- Adjustable dead time for PWM pulses
- Built-in overcurrent, overvoltage, and low water protection functions
- Provides switch-type Hall protection interface and linear Hall protection interface
- Integrated full-bridge inverter IGBT drive circuit for direct assembly of IGBT high-frequency induction heating devices
- Centralized control with minimal wiring, no additional debugging required
Applications:
- IGBT full-bridge inverter series resonant induction heating devices for frequency and power regulation
- Industrial drive control systems requiring precise radio frequency unit management
Related Models:
- ABB XVC722AE101
- ABB 3BHB002751R0102 VXC722AE02
- ABB NINT-72C
