Analog Current/Voltage Output IC693ALG392 GE FANUC

Description

The IC693ALG392 is an analog current/voltage output module belonging to the GE Fanuc Series 90-30 automation product line, designed for industrial automation system I/O expansion. It features 8 independent single-ended output channels, each configurable for either voltage or current output to meet diverse control needs. Voltage output options include 0-10V unipolar, -10 to +10V bipolar; current output options cover 0-20mA and 4-20mA, with the 4-20mA range ideal for long-distance, high-interference-resistance applications like process control and valve positioning.

Key performance specifications include 15 or 16-bit resolution (depending on output range): 0.5 microA for 4-20mA, 0.625 microA for 0-20mA, 0.3125 mV for 0-10V DC, and 0.3125 mV for -10 to +10V DC. It delivers ±0.1% voltage output accuracy and ±0.2% current output accuracy, with an 8-millisecond update rate per channel for reliable, real-time signal transmission.

Operating conditions range from 0 degrees Celsius to 55 degrees Celsius, with 5% to 95% non-condensing relative humidity. Power is supplied via 5V DC from the PLC backplane and an external 20-30V DC source, and it uses DIN rail mounting for easy installation. Additional features include open-circuit fault reporting for current mode channels, and it maintains or resets output values during power interference. Typical applications include controlling variable frequency drives, control valves, positioners, and transmitting analog data to recorders and data loggers.
