Analog Input Module ABB 70EA01a-E
Description
ABB Bailey NKSD01/NKSD11 Series Pre-configured Cables are standardized connection cables designed exclusively for industrial automation control systems, providing reliable electrical connections between modules, terminal boards, and other components in distributed control systems (DCS).
| Specification | Value |
|---|---|
| Rated Voltage | 60V DC / 25V AC |
| Rated Current | 1.0 A per core |
| Contact Resistance | ≤ 20 milliohms |
| Available Lengths | 10 cm, 15 cm, 20 cm, 25 cm, 30 cm |
Key Features:
- Factory pre-assembled with dedicated connectors, 100% electrically tested to reduce on-site wiring work
- Two variants: NKSD01 for digital signals and low-speed communication; NKSD11 with shielding for analog signals and high-speed communication
- Compact design with length options tailored to specific connection scenarios
- High reliability and consistent performance in industrial environments
Applications:
- Connection between adjacent ports on the same module (10 cm length)
- Interconnection between modules on the same substrate or within the same cabinet (15-25 cm lengths)
- Short-distance cross-terminal board connections (30 cm length)
- Use with Bailey Symphony Plus, INFI 90, and other DCS platforms
Related Models:
- NKSD01-10
- NKSD11-15
- NKSD01-20
- NKSD11-25
- NKSD01-30
