Asymmetric IGCT Module ABB 5SHY35L4520 AC10272001R0101
Description
ABB 5SHY35L4520 AC10272001R0101 is an asymmetric Integrated Gate Commutated Thyristor (IGCT) module, a core power device for connecting DC power sources and AC loads. Built on nearly 40 years of ABB’s power semiconductor technology, it integrates chip-level protection, temperature monitoring, and low-loss features to provide efficient, reliable power conversion solutions for medium and high-voltage industrial scenarios.
| Specification | Value |
|---|---|
| Product Model | ABB 5SHY35L4520 5SXE10-0181 AC10272001R0101 |
| Manufacturer | ABB |
| Product Type | IGCT Power Module |
| Series | 5SHY Series |
| Chip Technology | Trench-Gate Technology |
| Rated Voltage (Vce) | 1700V |
| Rated Current (Ic) | 450A (Tc=25 degrees Celsius), 300A (Tc=100 degrees Celsius) |
| Switching Frequency Range | 0-20kHz |
| On-State Voltage Drop (Vce(sat)) | 1.8V (typical, Ic=450A, Tc=25 degrees Celsius) |
| Maximum Junction Temperature (Tj) | -40 degrees Celsius to 150 degrees Celsius |
| Package Type | EconoDUAL3 Package |
| Isolation Voltage | 4000Vrms (minimum) |
| Recommended Drive Voltage Range | Vge=15V/-5V |
| Thermal Resistance (Rth(j-c)) | 0.08K/W (typical) |
| Dimensions | 140mm×110mm×22mm |
| Weight | Approximately 500g |
| Safety Certifications | UL 1557, IEC 60747-9, CE |
Key Features:
- Integrates chip-level protection and temperature monitoring for enhanced reliability
- Uses patented Trench-Gate technology and advanced packaging to reduce switching loss by over 15%
- Enables efficient AC-DC and DC-AC power conversion via precise gate signal control
- Supports buffer-free operation and stable performance under high-load conditions
- High power density and excellent thermal stability
Applications:
- Medium and high-voltage industrial converters
- Grid-tied photovoltaic inverters
- Industrial variable frequency drives
- High-power power supply systems
- Power plants, steel mills, cement plants, and papermaking facilities
Related Models:
- 5SHY3545L0003
- 5SHY35L4503
- 5SHY35L4510
- 5SHY35L4512
- 5SHY4045L0001
