Baseplate Module Foxboro P0926JMA for Distributed Control Systems

Description

The Foxboro P0926JMA Baseplate Module is a DIN rail-mounted 8-slot baseplate designed for the Foxboro I/A Series Distributed Control Systems (DCS). Serving as a flexible, scalable platform for industrial automation applications, it enables the creation of custom control solutions by supporting the installation of various components. Key technical specifications include 8 slots compatible with I/O, communication, and other control modules, a 24 VDC power input, and a maximum power consumption of 100W. It features an IP20 protection rating, with an operating temperature range of -40 degrees Celsius to 70 degrees Celsius and a storage temperature range of -55 degrees Celsius to 85 degrees Celsius. The unit measures 216mm x 330mm x 133mm and weighs 6.8 kg. Core features include a modular design to accommodate diverse module types, hot-swappable module support for maintenance without system interruption, high-speed backplane bus communication for efficient inter-module data transfer, and a rugged construction suitable for harsh industrial environments. This baseplate provides mechanical support and electrical connectivity to build tailored DCS configurations for a wide range of industrial automation use cases.
