BENTLY NEVADA 133323-01 Comms Gateway I/O Module

Description

The BENTLY NEVADA 133323-01 Comms Gateway I/O Module is part of the 3500/92 series, designed to enable seamless communication between diverse devices and systems within industrial networks by acting as an interface for data exchange and control signal transmission/reception. Key communication features include Ethernet TCP/IP functionality with an RJ45 connection for 10BASE-T star-configured Ethernet, plus serial (RS232/RS422/RS485) communication support. It is compatible with multiple protocols: Modicon Modbus via serial links, Modbus/TCP for TCP/IP Ethernet communication, and a proprietary Bently Nevada protocol for interaction with 3500 rack configuration and data acquisition software. The module provides extensive access to all rack monitoring values and statuses, supporting integration with process control and other automation systems, as well as Ethernet communication with 3500 rack configuration and data acquisition tools. It retains compatibility with the original 3500/90’s communication interfaces and protocols (excluding main value Modbus registers) and includes a configurable Modbus register utility. Physical specifications include dimensions of 241 mm x 24.4 mm x 99.1 mm, weight of 0.44 kg (0.96 lb.), requiring 1 full-height front slot for the monitor module and 1 full-height rear slot for I/O modules. An operating OK LED indicates proper function.
