BENTLY NEVADA | 136180-01 | 3500/92 Communication Gateway Module

Description

The BENTLY NEVADA 3500/92 Communication Gateway Module (Model 136180-01) is a core component of the 3500 series monitoring system, designed to enable seamless data exchange and communication between the 3500 system and external devices or control systems, expanding the system’s functionality and application scope. It serves as a central communication hub, collecting critical equipment status data from 3500 series modules such as vibration monitors, tachometers, and process variable sensors, then transmitting this data to external systems for real-time monitoring, fault diagnosis, predictive maintenance, and performance optimization.

Key technical specifications include a typical 24 VDC power supply with 5W typical power consumption, and a wide operating temperature range of -40 degrees Celsius to +85 degrees Celsius, with operating humidity from 0% to 95%, ensuring reliable performance in harsh industrial environments. It supports multi-protocol communication: the 10/100Base-T Ethernet interface is compatible with Modbus/TCP and OPC UA, while serial interfaces include RS-232, RS-422, and RS-485, supporting Modbus RTU/ASCII. Additional features include 8 analog input and 8 analog output channels with 0-10VDC or 4-20mA DC input signals, 16-bit resolution, and ±0.05% accuracy. Its modular design allows for easy installation and maintenance, with configurable communication parameters and data formats to adapt to diverse industrial automation integration needs.
