BENTLY NEVADA 330180-50-00 3300 XL Proximitor Sensor

Description

The BENTLY NEVADA 330180-50-00 3300 XL Proximitor Sensor is a component of the 3300 XL 8mm Proximity Transducer System, designed for non-contact distance and position monitoring in industrial applications. With physical dimensions of 7.8x6x6.4cm, a net weight of 0.22kg, and package weight of 1kg, it offers flexible installation options, including high-density DIN rail mounting and traditional panel mounting, with an electrically isolated mounting base for added safety. Key technical specifications include an operating temperature range of -51 degrees Celsius to 100 degrees Celsius (-60°F to 212°F), a linear measurement range of approximately 2.0mm (80mil), maximum power consumption of 12mA, and a supply voltage range of -17.5Vdc to -26Vdc. A standout feature is its 100% interchangeability with all 3300 XL 8mm system components—probes, extension cables, and other Proximitor sensors—without requiring separate matching or on-site calibration, fully meeting API 670 standards for precision and reliability. It is highly resistant to radio frequency interference, and compatible with any non-contacting 3300-series 5mm or 3300 XL 8mm probe paired with its extension cable, converting signals from the probe into a voltage proportional to the distance between the probe tip and the monitored surface.
