BENTLY NEVADA 3500/42M 140734-02 Proximitor Seismic Monitor

Description

The BENTLY NEVADA 3500/42M 140734-02 Proximitor Seismic Monitor is a four-channel machine condition monitoring component designed to track and analyze vibration and position parameters for industrial equipment. It supports inputs from 1 to 4 proximity, velocity, or acceleration sensors, converting raw signals into actionable vibration and position readings. Key features include channel pairing functionality, allowing the four channels to operate as two groups to execute up to two designated monitoring functions simultaneously, such as pairing channels 1 and 2 for one parameter set and channels 3 and 4 for another.

Users can program each channel via 3500 rack configuration software to monitor and report a wide range of parameters, including radial vibration, thrust position, REBAM, acceleration, differential expansion, eccentricity, and velocity. The monitor compares conditioned signals against user-programmable alarm setpoints, triggering alerts in real time to protect machinery and relay critical equipment status data. Technical specifications include a typical power consumption of 7.7 watts, a standard input/output impedance of 10 kΩ for proximity and acceleration inputs, and front-panel LEDs: an OK LED to indicate normal operation, and a TX/RX LED to show communication status with other modules in the 3500 rack.
