BENTLY NEVADA 3500/92 136180-01 Communication Gateaway Module

Description

The BENTLY NEVADA 3500/92 136180-01 Communication Gateway Module is a component of the Bently Nevada 3500 series monitoring system, designed for industrial automation applications to connect the 3500 system with external devices or systems, enabling data exchange, communication, and expanded system functionality and application scope. Key functions include data collection from external devices, data transmission from the 3500 system to external platforms, and system integration for shared data and collaborative operation.

This module features multi-protocol support, including RS232, RS422, RS485, Ethernet TCP/IP, Modbus, Modbus/TCP, and a proprietary Bently Nevada protocol for communication with 3500 rack configuration and data acquisition software. It offers flexible configuration, allowing users to adjust communication parameters, data formats, and communication rates via software to meet diverse application needs, and its modular design simplifies installation and maintenance.

Technical specifications include a 24VDC operating voltage, operating temperature range of -40 degrees Celsius to 85 degrees Celsius, and operating humidity of 0% to 95%. It has 8 analog input channels and 8 analog output channels, accepting 0-10VDC or 4-20mA DC input signals with 16-bit resolution and ±0.05% accuracy. Physical specs include dimensions of 241mm x 24.4mm x 242mm, weight of 0.82kg, typical power consumption of 5.0 watts, and SIL 2 functional safety rating.
