Dual-Channel Synchronization Module ABB SYN5302a-Z 3BHB006716R0277
Description
ABB SYN5302a-Z 3BHB006716R0277 is an industrial-grade automatic synchronizer from ABB’s SYNCHROTACT 5 series, designed for safe grid connection operations between power system generators and grids or busbars. It provides high-precision, high-reliability core support for grid connection to ensure stable power system operation.
| Specification | Value |
|---|---|
| Brand | ABB |
| Product Series | SYNCHROTACT 5 Series Automatic Synchronizer |
| Product Type | Industrial-Grade Automatic Synchronizer |
| Model | SYN5302a-Z 3BHB006716R0277 |
| Operating Modes | Manual Mode, Automatic Mode |
| Supply Voltage | 24VDC or 110-230VAC |
| Voltage Class | 277V |
| Frequency Measurement Range | 45Hz-65Hz |
| Synchronization Accuracy | Angle error ≤1 degree |
| Input Types | Multi-channel voltage input, frequency input |
| Output Types | Synchronization signal, control signal, alarm signal |
| Cooling Method | Forced air cooling |
| Supported Communication Protocols | Modbus, Profibus, LON, IEC 61850 |
| Communication Interfaces | RS-485 interface, Ethernet interface |
| Operating Temperature Range | -25 to 70 degrees Celsius |
| Mounting Methods | Cabinet mounting, DIN rail mounting |
| Compatible Generator Types | Synchronous generator, asynchronous generator |
Key Features:
- Real-time precise measurement of power frequency, phase, and voltage parameters, with automatic control algorithms to execute grid connection processes
- Complete fault protection and self-monitoring mechanism, with rapid response to abnormal conditions to block improper operations
- Dual-channel redundant architecture for high reliability, supporting hot backup operation for uninterrupted control
- Compatible with multiple industrial communication protocols and generator types, enabling flexible integration into various power control systems
- Supports debugging via SynView software, with remote monitoring capabilities to simplify deployment and maintenance
Applications:
- Thermal, hydro, nuclear, and new energy power generation industries
- Distributed energy systems and industrial self-owned power generation
- Power distribution systems and data center power support
- Substation synchronization operations and backup power switching
Related Models:
- ABB SYN5100
- ABB SYN5200
- ABB SYN5201
- ABB SYN5202
- ABB SYN5500
- ABB SYN5302A-Z.V5777 3BHB006716R5777
