Electrical Distribution Breaker ABB 1JNL100100-591 Control Systems
Description
ABB Relion 615 Series F615 Feeder Protection and Control Device is a specialized electrical distribution and protection unit designed for utility substations and industrial power distribution systems, integrating multiple functions in a single compact device.
| Specification | Value |
|---|---|
| Maximum Rated Current (Formulaair Series) | 4000A |
| Maximum Rated Uninterrupted Current (Emax2 Series) | 6300A |
| Maximum Short Circuit Breaking Capacity (Emax2 Series) | 200kA |
| Supported Communication Protocols | IEC 61850, IEC 60870-5-103/104, Modbus, DNP3.0 |
Key Features:
- Integrated protection, control, measurement, monitoring, and management functions to reduce equipment count and space
- High-sensitivity earth fault protection including directional/non-directional overcurrent, zero sequence voltage protection, and intermittent earth fault protection
- Hot-swappable plug-in design for safe, quick installation, testing, and maintenance without power interruption
- Universal interchangeable trip units (Formulaair Series) for flexible configuration across frame sizes
- Built-in self-test functions including trip/close circuit monitoring and PT/CT open circuit monitoring
Applications:
- Protection of overhead lines, cable feeders, and distribution substation busbars in utility and industrial grids
- Use in power substations, power plants, and industrial facilities including cement, metallurgy, petrochemical, and semiconductor plants
- Compatibility with radial, loop, and mesh distribution grids including those with distributed generation
Related Models:
- ABB Emax2 Series E1.2, E2.2, E4.2, E6.2
- ABB Formulaair Series
- ABB S200 Series
- ABB XT Series
