GE FANUC IC694MDL754 RX3i Output Module

Description

The GE FANUC IC694MDL754 RX3i Output Module is a discrete output unit from the RX3i series, designed for industrial automation control systems. It features 32 discrete output points with positive logic (source-type) output, and is equipped with Electronic Short Circuit Protection (ESCP) for enhanced operational safety.

Key electrical specifications include an output voltage range of 10.2 to 28.8 VDC, output current ratings of 0.5 amps per point and 4 amps per group, and a total rated current of 20A. The module supports an output frequency of 16Hz, with a response time of less than 1 microsecond, ensuring fast, reliable signal transmission. It has a wide operating temperature range of -25 to 70 degrees Celsius, storage temperature range of -40 to 85 degrees Celsius, and can withstand non-condensing humidity of 5% to 95%, vibration of 5G (10 to 500Hz), and shock of 10G (11ms) for robust performance in harsh industrial environments.

Constructed as a modular unit with a compact 28mm size, it uses field-mount installation and has firmware version V1.0.0. The module provides isolation between output groups, and is ideal for controlling industrial devices such as relays, valves, motors, and indicators. Typical applications include discrete manufacturing process control, packaging material handling, automotive manufacturing, and semiconductor manufacturing.
