GE FANUC IC695LRE001 RX3i Serial Bus Transmitter Module

Description

The GE FANUC IC695LRE001 RX3i Serial Bus Transmitter Module is a communication component for PACSystems RX3i automation systems, designed to enable data transfer between PACSystems RX3i Universal Backplanes (IC695 models) and serial expansion or remote backplanes (IC694 or IC693 models). It must be installed in the expansion connector at the right end of the Universal Backplane, and hot-swapping is not allowed; power must be removed before installation or removal. After inserting the module, users need to tighten the two captive corner screws to a maximum recommended torque of 4.4 inch-pounds.

Key technical specifications include a 24VDC operating voltage with a maximum current draw of 1.5A, physical dimensions of 198mm x 130mm x 60mm, and a weight of approximately 0.5kg. The module operates in an environment with temperatures ranging from 0 to 60 degrees Celsius and relative humidity of 5-95% (non-condensing). It integrates over-current, over-heat, and short-circuit protection functions to prevent power overload and abnormal operating conditions, ensuring reliable system performance during serial backplane communication tasks.
