GE FANUC IS230TVBAH4A Vibration Input Assembly

Description

GE FANUC IS230TVBAH4A Vibration Input Assembly is an RST analog I/O board belonging to the Mark V series, designed for gas turbine control systems. As a key component, it scales and conditions a wide range of analog signals read from terminal boards installed on I/O cores R1, R2, and R3. Supported signal types include LVDT inputs, servo valve outputs, thermocouple inputs, 4-20 mA inputs and outputs, vibration inputs, relay driver outputs, pulse inputs, voltage inputs, as well as generator and line signals. The assembly features dedicated connectivity: it uses a 3PL connector to write partial signals to STCA boards, and a JE connector to send and receive generator and line signals with TCQC boards. It also specializes in scaling and conditioning 4-20 mA input signals such as compressor stall detection signals and fuel flow pressure signals, ensuring accurate, processed data for critical gas turbine control operations.
