GE IC754VSB06MTD QuickPanel View Model
Description
GE IC754VSB06MTD QuickPanel View Model is an industrial-grade touch display terminal, positioned as a mid-range color HMI in the QuickPanel View series, serving as a visual operation entry for industrial control equipment.
| Specification | Value |
|---|---|
| Display Type | 8-inch TFT color LCD screen, resistive touch |
| Resolution | 800×600 pixels |
| Color Depth | 65536 colors (16-bit) |
| Backlight | Cold cathode fluorescent lamp, half-life approximately 50000 hours |
| Processor | 300MHz XScale PXA255 32-bit RISC processor |
| Storage Configuration | 32MB DRAM, 32MB non-volatile flash, 512KB battery-backed SRAM, 512KB non-volatile boot ROM |
| Power Supply | 24VDC ±20%, max input 30VDC, power consumption ≤15W, 3-pin connector |
| Front Panel Protection | NEMA 4/4X/12, dust and water resistant |
Key Features:
- Industrial-grade TFT screen with stable viewing angle, suitable for multi-angle operation in workshops
- Resistive touch screen supports single-point precise touch and glove operation, with wear-resistant coating on surface
- Low-power XScale PXA255 processor paired with Windows CE embedded OS, enabling efficient operation of configuration software with millisecond-level response
- Valox 3706 engineering plastic housing with impact resistance and high temperature resistance, plus power LED indicator for quick status checking
- Battery-backed SRAM ensures data retention during power loss
Applications:
- Equipment monitoring, parameter configuration and process control in industrial automation systems
- Harsh industrial environments such as automotive manufacturing, chemical, power, and water treatment industries
Related Models:
- IC754VKI08CTD
- IC754VSL06MTD
- IC754VSI06STD-LH
- IC754VSF12CTD
