GE QuickPanel IC754CSX06CTD Control Panel for Automation
Description
GE QuickPanel IC754CSX06CTD Control Panel for Automation is a compact input module for industrial automation systems, designed to collect high-density discrete signals and integrate seamlessly with GE PLC platforms.
| Specification | Value |
|---|---|
| Number of Discrete Input Channels | 32 |
| Input Voltage Range | 24V DC (19.2 to 30V) |
| Minimum Input Current | 2mA |
| Input Response Time | Less than 1ms |
| Power Consumption | 1.7W + (0.36 × number of active channels) |
| Dimensions | 120mm × 70mm × 90mm |
| Weight | 250g |
| Protection Rating | IP20 (estimated) |
| Operating Temperature Range | -40 to 70 degrees Celsius |
| Operating Humidity | 60% non-condensing |
| Logic Type | Sink logic (low level active) |
| Firmware Version | V1.0.0 |
| Operating System | PLC system, integrated with GE industrial automation platform |
Key Features:
- High-density 32-channel discrete input support for complex industrial signal collection
- Fast input response time under 1ms for accurate real-time equipment status monitoring
- Channel-to-channel isolation design reduces signal interference and improves data stability
- Built-in over-voltage protection circuit prevents module damage from voltage fluctuations
- Compact, lightweight structure saves installation space and simplifies system integration
- Low power consumption design reduces overall system energy usage
Applications:
- Industrial automation systems as a PLC input module for collecting switch and sensor data
- Complex indoor industrial environments requiring stable, high-speed signal acquisition
- Chemical, petroleum, aerospace, and electrical equipment monitoring and control systems
