HONEYWELL 900U02-0100 ControlEdge HC900 IO Module

Description

The HONEYWELL 900U02-0100 is a dedicated IO module for the ControlEdge HC900 hybrid loop and logic control system, which features a modular design for flexible configuration. As part of this advanced control platform, the module supports the system’s core capabilities, including high-quality PID loop control and robust analog processing that outperforms most standard logic controllers, without compromising logic control performance. The system executes all logic and algorithm function modules in a single, independent fast scan cycle, with logic and analog function modules running simultaneously to enable optimized hybrid control strategies for process equipment control and data management needs.

Specific technical specifications for the 900U02-0100 include a current input type compatible with 2, 3, or 4-wire devices, a maximum of 16 line-monitored input channels per module, 16-bit A/D converter resolution, and an input range of 4-20 mA. The ControlEdge HC900 platform supports star and ring topologies for connecting expansion IO racks and CPM racks, enabling scalable system expansion. It also features open Ethernet connectivity with Modbus TCP protocol for integration with third-party HMI/SCADA software, and uses a Windows-based configuration tool for simplified design, programming, and maintenance, with advanced monitoring and in-run configuration adjustment capabilities.
