IC693PTM101 GE Power Transducer Module
Description
IC693PTM101 GE Power Transducer Module is a power sensing component designed for the GE 90-30 series PLC system, used to collect, calculate, and transmit electrical parameters for industrial automation applications.
| Specification | Value |
|---|---|
| Input Voltage Range | 10–120V AC |
| Input Current Range | 0–7.5A RMS |
| Input Frequency Range | 35–70Hz |
| Measurement Resolution | 14-bit |
| Data Processing at 50Hz | Calculation cycle 20ms, delay 15ms |
| Data Processing at 60Hz | Calculation cycle 16.67ms, delay 16.67ms |
| Backplane Isolation Voltage | 1500V AC |
| Power Consumption | Approximately 4W |
| Operating Temperature | 0 to 60 degrees Celsius |
| Operating Humidity | 5%–95% (no condensation) |
Key Features:
- Consists of three core components: processing module, interface board, and 1-meter interface cable for flexible installation and stable signal transmission
- Measures multiple electrical parameters including RMS voltage, RMS current, active power, reactive power, apparent power, energy, power factor, and frequency
- Supports data reporting and fault monitoring functions to provide reliable power data for 90-30 series PLC systems
- High 14-bit measurement resolution ensures accurate data collection and calculation
Applications:
- Industrial energy management systems for energy consumption tracking and optimization
- Power monitoring systems for real-time electrical parameter tracking of industrial equipment
- Fault diagnosis systems for detecting and alerting on abnormal power conditions
Related Models:
- IC693PTM100 (90-30 series power transducer module with 0.5-meter interface cable)
- IC693PWR322 (90-30 series standard DC power module)
- IC693MDL654LT (90-30 series 16-point photoelectric isolated DC digital output module)
