IC695PSA040 GE FANUC Multi-Purpose Power Supply

Description

The IC695PSA040 is a 40-watt power supply module belonging to the PACSystems RX3i series, engineered specifically for industrial automation systems. It features a wide input voltage range of 85 to 264 VAC or 100 VDC to 300 VDC, enabling seamless adaptation to diverse industrial power environments and requirements. The module delivers three output voltages: +5.1 VDC, +24 VDC (relay output), and +3.3 VDC, with the +3.3 VDC output dedicated exclusively to internal IC695 RX3i modules. For installation and wiring, each terminal accepts 14 AWG to 22 AWG wire, with a maximum current rating of 6 amps per terminal; only one unit can be installed on a PACSystems RX3i universal backplane, occupying two slots. Key performance features include a power conversion efficiency of over 85%, reducing energy waste and system heat generation to enhance overall stability and service life. It also integrates comprehensive protection functions: overload protection, short-circuit protection, and overheat protection, preventing equipment damage from abnormal conditions to boost system safety and reliability. With high isolation voltage to resist electrical interference and a compact design that saves cabinet space for easy integration and maintenance, this module is widely used to power programmable logic controllers (PLCs), sensors, and actuators in industrial automation setups.
