IGCT Commutated Thyristor Module 5SHX08F4502 ABB
Description
5SHX08F4502 ABB IGCT Commutated Thyristor Module is a high-performance reverse-conducting gate-commutated thyristor module designed for high-voltage, medium-power power conversion and control systems. It combines the advantages of IGBT and GTO technologies to deliver efficient, stable power control with integrated design for simplified installation and operation.
| Specification | Value |
|---|---|
| Package Type | TO-247 |
| Rated Voltage | 4500V |
| Rated Current | 800A |
| Operating Temperature Range | -40 to 150 degrees Celsius |
| Control Power Consumption | 10-100W |
| Typical Switching Frequency | 500 Hz |
| Maximum Short Switch Pulse Train Frequency | 40 kHz |
| Turn-On Time | Less than 3 microseconds |
| Turn-Off Time | Less than 6 microseconds |
Key Features:
- Advanced IGCT technology enables high switching speed with slow turn-on loss definition and direct series connection using small snubbers
- Press-pack housing provides high reliability, excellent thermal cycling performance, and 1+1 redundancy via additional IGCT for fault-mode short circuits, reducing overall system costs
- Balanced resistors and small RC snubbers ensure symmetrical voltage balancing under critical operating conditions
- Direct fiber optic control for high EMI immunity and precise timing with turn-off time deviation less than 800 nanoseconds
- Patented free-floating silicon technology optimizes low on-state and switching losses
- Built-in diagnostic functions enhance system safety; reverse-conducting capability improves efficiency and reduces voltage drop
- Space radiation tolerant design for demanding environments
Applications:
- Rectifier power supplies
- Motor drives and variable frequency drives
- Inverters for renewable energy and industrial systems
- Welding equipment and electric furnaces
Related Models:
- 5SHX 1060H0001
- 5SHX series IGCT modules
