IS200EPDMG1BAA GE Exciter Power Distribution Module
Description
IS200EPDMG1BAA GE Exciter Power Distribution Module is an RST analog I/O board produced by General Electric, belonging to the Mark V series for gas turbine control systems. It scales and conditions a wide range of analog signals read from terminal boards mounted on I/O cores R1, R2, and R3, and also serves as a power distribution unit for exciter system components including control boards, I/O boards, and protection boards.
| Specification | Value |
|---|---|
| Product Type | Exciter Power Distribution Module / Analog I/O Board |
| Series | Mark V, EX2100 Excitation Control |
| Input Voltage | 125V DC, 115V AC |
| Output Voltage | 24V DC, +62.5V, -62.5V |
| Maximum Current | 10A |
| Power Efficiency | Greater than 85% |
| Operating Temperature Range | -20 to 70 degrees Celsius |
| Dimensions | 230x170x85 millimeters |
| Weight | Approximately 2 kilograms |
Key Features:
- Scales and conditions multiple analog signals including LVDT inputs, thermocouple inputs, 4-20 mA inputs/outputs, vibration inputs, and generator/line signals
- Integrated protection functions including overload, short circuit, overvoltage, and overcurrent protection
- Modular design for easy replacement and maintenance
- LED status indicators and toggle switches for power management and visibility
- Power filtering and isolation to improve power quality and reduce interference
- 12 plug connectors for signal and power connections, including 2 twelve-position connectors, 9 two-position connectors, and 1 three-hole female connector
Applications:
- Gas turbine control systems
- Power generation facilities including power plants and substations
- Industrial automation systems in chemical, metallurgy, and petroleum industries
- EX2100 excitation control systems for exciter component power supply
Related Models:
- IS200EPDMG1B
- IS200EPDM
- IS200TCQAH1B
- IS200STCAH2B
