IS200TBTCH1CBB | Thermocouple Terminal Board | GE FANUC

Description

The IS200TBTCH1CBB is a Thermocouple Terminal Board integrated into the GE FANUC Mark VI control system, specifically engineered for control systems of gas turbines and steam turbines. As a multi-functional terminal board, its core function is to connect and process signals from various sensors, converting analog signals into digital signals for system processing and monitoring. It features 32 channels, supporting diverse input types including thermocouples (such as K, J, S, T types), RTD, and 4-20mA signals, with output type limited to 4-20mA signals. Key technical specifications include a 24V DC operating voltage, an operating temperature range of -40 degrees Celsius to +85 degrees Celsius, and an IP65 protection rating. Constructed from aluminum alloy, it uses DIN rail mounting for easy installation, with dimensions of 177.8 x 355mm, weight of 2 kg, and power consumption of less than 10W. For seamless system integration, it supports multiple communication interfaces including RS-232, RS-485, and Ethernet, making it a critical component for reliable signal management in turbine control applications.
