IS200VAICH1DAA Analog Input Board GE Mark VI

Description

The IS200VAICH1DAA Analog Input Board is a component of the GE Mark VI series control system, designed as an analog I/O board for industrial signal acquisition and processing. Its core function is to collect and condition analog signals such as temperature, pressure, flow, vibration, and generator/line signals, then convert them into digital signals for system analysis and control. Key features include high precision, high reliability, and a modular design that supports easy installation and maintenance, plus digital filtering technology to reduce noise interference and improve signal quality.

Technical specifications for the board include: an input voltage range of 90-132VAC or 180-264VAC, output voltage of 24VDC, rated power of 200VA, and an operating temperature range of -40 degrees Celsius to 70 degrees Celsius. It measures 3.5 inches x 5 inches x 2 inches, with 20 analog input channels (supporting ±1mA or 4-20mA current inputs) and 4 analog output channels (0-5VDC voltage output). It is equipped with a high-performance processor, 1024KB RAM, and multi-Ethernet communication interfaces, and integrates seamlessly with Mark VI systems.

This board is widely applied in industrial automation scenarios including power plants, oil and chemical industries, and gas turbine control systems, for monitoring equipment operating parameters and collecting process variables.
