IS220PTURH1B GE Fanuc High-Performance Control Module
Description
IS220PTURH1B GE Fanuc High-Performance Control Module is a high-performance I/O module belonging to the GE Fanuc Mark VIe series, designed as part of gas turbine control systems to manage PROFIBUS slave I/O data exchange.
| Specification | Value |
|---|---|
| Module Type | PROFIBUS DPV0 Class 1 Master, Mark VIe Series I/O Module |
| Working Voltage | 24Vdc, optional 120Vac in some scenarios |
| Power Input Range | 27.4Vdc – 28.6Vdc |
| Maximum PROFIBUS Slaves | 125 |
| Transmission Rate Range | 9.6KBaud – 12MBaud |
| I/O Throughput (Semi-Boolean Semi-Analog Mode) | 500 inputs / 500 outputs, 40ms frame rate |
| Operating Temperature | -20 to 55 degrees Celsius, extendable to -40 to 70 degrees Celsius in some scenarios |
| Certifications | UL, ATEX (Zone 2), DEMKO 12 ATEX 1114875X |
Key Features:
- Acts as a PROFIBUS DPV0 Class 1 master to manage cyclic I/O data exchange and diagnostic information with slave devices
- Hot backup redundancy design with automatic master-standby switchover via dual I/O Ethernet connections for high system availability
- Equipped with PROFIBUS RS-485 and Ethernet interfaces for flexible network integration
- Modular design enables easy maintenance and replacement; LED indicators provide visual diagnostic status
- Supports PROFIBUS DP protocol, processed via Hilscher GmbH COM-C PROFIBUS communication module based on Siemens ASPC2 technology
Applications:
- Gas turbine control systems, including fan control and speed regulation
- Industrial automation in power, chemical, and oil and gas industries for managing motors, valves, and other field devices
Related Models:
- IS220PTURH1A
- IS220PPRFH1B
- IS220PAICH2A
- IS220PRTDH1A
- IS220PTCCH1A
