Motion Control Processor Module GE IS200DSPXH1DBD
Description
GE IS200DSPXH1DBD Motion Control Processor Module is a printed circuit board designed by GE for the Mark VI series, part of the Speedtronic product line. It serves as a real-time digital signal processing core for industrial control systems, handling signals from sensors, actuators, and other equipment to enable control, monitoring, and protection of large industrial systems.
| Specification | Value |
|---|---|
| Processor Core | TI TMS320C6748 fixed/floating-point DSP with Harvard bus structure |
| Input Voltage | 24VDC |
| Output Voltage | 5VDC |
| Operating Temperature | -40 to 85 degrees Celsius |
| Protection Rating | IP65 |
| Weight | 2.2 pounds |
| Task Scheduling Delay | 8.7 microseconds ± 0.3 microseconds |
| ADC Configuration | 2-channel 16-bit ADC, 200kSPS sampling rate, synchronized with RC anti-aliasing filter |
| Peripheral Bus Clock | 150MHz |
Key Features:
- Highly stable and efficient real-time signal processing with deterministic low-latency response
- Wide adaptability to harsh industrial environments with robust IP65 protection
- Good scalability to meet diverse industrial control application requirements
- Integrated FPGA coprocessor and industrial-grade Ethernet interface for seamless system integration
- Easy maintenance with user-friendly design
Applications:
- Control and monitoring of innovative series drives and EX2100 exciters
- Real-time signal processing for large industrial systems including wind turbine pitch control
- Closed-loop control of servo motors to eliminate micro-vibration caused by command delay
- Data acquisition and processing from industrial sensors and actuators
Related Models:
- GE IS200DSPXH1DBC
- GE Mark VI Series Control Modules
- GE Speedtronic Series Industrial Control Components
